2344656-4 TE Connectivity 100% cross INGKE 2344656-4

INGKE 2344656-4 100% replace 2344656-4 TE Connectivity RF antennas

Part No.:2344656-4 TE Connectivity

INGKE Part No.:YKRF-2344656-4

Made in China:INGKE TECHNOLOGY

Description:2344656-4 TE Connectivity RF antennas

Lead Time:1-2 Weeks

MOQ:1PCS

Manufacturer:TE Connectivity

TE Internal #:2344656-4

TE Internal Description:WLAN DUAL BAND ANTENNA FPC V 200mm

Wireless Application:Bluetooth, Wi-Fi, Zigbee

Mounting Location:Internal/Embedded

Mounting Type:Adhesive

Antenna Termination:MHF, MHF1, U.FL, UMCC

Antenna Type:Flexible PCB (FPC)

Impedance (Ω):50

VSWR (Max):<2:1

Antenna Operation:Passive

Frequency Band (MHz):2400 – 2500, 5150 – 5875

Nominal Frequency Range:2400 – 5950

Peak Gain (dBi):0 < 3

Gain (Max) (dB):2

Product Height:.19 mm [ .007 in ]

Product Length:30 mm [ 1.181 in ]

Product Width:9.5 mm [ .374 in ]

Product Diameter:1.13 mm [ .044 in ]

Cable Length:.2 m [ .66 ft ]

Cable Insulation Diameter (Max):.7 mm [ .028 in ]

Directionality:Omnidirectional

Wireless Standard:802.11 a/b/g/n/ac/ad, Bluetooth, ZigBee & Wi-Fi

RoHS Compliant and REACH

100% compatible,100% test, warranty for 60 months

Factory with UL,supplier of Marvell & Honeywell
