ANT-DB1-HDP-TNC TE Connectivity 100% cross INGKE ANT-DB1-HDP-TNC

INGKE ANT-DB1-HDP-TNC 100% replace ANT-DB1-HDP-TNC TE Connectivity RF antennas

Part No.:ANT-DB1-HDP-TNC TE Connectivity

INGKE Part No.:YKRF-ANT-DB1-HDP-TNC

Made in China:INGKE TECHNOLOGY

Description:ANT-DB1-HDP-TNC TE Connectivity RF antennas

Lead Time:1-2 Weeks

MOQ:1PCS

Manufacturer:TE Connectivity

TE Internal #:ANT-DB1-HDP-TNC

TE Internal Description:Antenna Horz Tri-Band RG174 2M TNC

Wireless Application:5G, Cat-M/NB-IoT, Cellular, LTE

Mounting Location:External

Mounting Type:Adhesive

Antenna Termination:RP-TNC, TNC

Antenna Type:Module

Impedance (Ω):50

VSWR (Max):<1.5:1

Frequency Band (MHz):824 – 960

Nominal Frequency Range:698 – 2700

Peak Gain (dBi):0 < 3

Product Height :12.4 mm [ .49 in ]

Product Length:132.3 mm [ 5.21 in ]

Product Width :20 mm [ .79 in ]

Cable Length :3 m [ 9.84 ft ]

RoHS Compliant and REACH

100% compatible,100% test, warranty for 60 months

Factory with UL,supplier of Marvell & Honeywell
