ADFGP.50A.07.0100C Taoglas 100% cross INGKE YKRF-ADFGP.50A.07.0100C

INGKE YKRF-ADFGP.50A.07.0100C 100% replace ADFGP.50A.07.0100C Taoglas

Part No.: ADFGP.50A.07.0100C Taoglas
INGKE Part No.: YKRF-ADFGP.50A.07.0100C

Made in China: INGKE TECHNOLOGY

Description:ADFGP.50A.07.0100C Taoglas RF antennas
Lead Time: 1-2 Weeks
MOQ: 1PCS

Antenna Connector Type:U.FL

Application:UAVs, Robotics, Transportation, Autonomous Vehicles, Agriculture, Navigation, RTK

Cable Length :60 mm

Cable Type:100 mm RF1.13

Center Frequency:1176.45 MHz, 1227.6 MHz, 1561 MHz, 1575.42 MHz, 1602 MHz

Electrical Type:Active Embedded

Ground Plane Size:50 mm x 50 mm

Height:16.8 mm

Impedance:50 Ohms

Length:50 mm

Maximum Frequency:1602 MHz

Maximum Operating Temperature:+ 85 C

Mechanical Style:Patch

Minimum Frequency:1176.45 MHz

Minimum Operating Temperature:- 40 C

Mounting Style:PCB Mount

Polarization:RHCP

Product:PCB Antennas

Protocol - GPS, GLONASS:BEIDOU, Galileo, GLONASS, GNSS, GPS

Series:ADFGP.50A

Standard Pack Qty:50

Style:Stacked

Subcategory:Antennas

Termination Style:Pin, Dual

Type:MIMO Antenna

Width:50 mm

RoHS Compliant and REACH

100% compatible, 100% test,  warranty for 60 months
Factory with UL, supplier of Marvell & Honeywell
